JVC, KD-T402 CD/RADIO UNIT

JVC KD-T402 CD Receiver with USB/AUX Input

Features

• Digital Track Expander
• Steering Remote Control Ready
• Android Music Playback (AOA 2.0)
• CD Receiver with USB/AUX Input
• FLAC Compatible
• 15-Preset EQ

Specifications

Media Playback

• MP3 Compatible with Tag CD/USB
• WMA Compatible with Tag CD/USB
• WAV Compatible with Tag USB
• FLAC Compatible with Tag USB ( Up to 48kHz/16bit )

Android Control

• Android Music Playback (AOA 2.0)

USB

• Position Front
• USB Power Supply (1.0A)
• Drive Change Mode for Mass Storage Class

Tuner

• Radio Data System (RDS)
• Tuner Type
• Digital Processing Tuner
• Preset Stations 18FM + 6AM
• Strong Station Memory (for FM)
• Radio Timer (Once/Daily/Weekly)
• Tuner Preset Memory (for power disconnection)
• FM
  • Frequency Range 87.5 - 108.0MHz
• AM
  • Frequency Range (MW) 531 - 1,611kHz (9kHz), (LW) 153 - 279kHz (9kHz)

Audio

• Maximum Power Output 50W x 4 / 50W x 2 +Subwoofer (4 ohms) 50W x 1
• Full Bandwidth Power (at less than 1%THD) 22W x 4
• MOS-FET Amplifier
• Sub woofer Direct Connection (Mono Lch)
• EQ (3-Band Parametric EQ)
• Preset EQ (15-Preset)
• Digital Track Expander
• Loudness Control (Off/Low/High)
• High-Pass Filter/Low-Pass Filter
• Bass Boost

Inputs and Outputs

• AUX Input 1 (Front)
• Line Output Terminals (Pair) 1 Pair (Rear/Subwoofer Selectable)
• Subwoofer Output with Level/Frequency Control (Level -8 - +8)
• Subwoofer Output Level 2.5V
• Pre-Output Level 2.5V

Display

• Display Type VA LCD Display
• LCD Color White
• Key Color Red
• Russian Text Display Compatible
• Spanish Text Display Compatible
• French Text Display Compatible
• Auto Dimmer
• Brightness Control

General

• Detachable Face Panel
• Steering Remote Control Ready
• Back Up Memory
• ISO Connector
• Dimensions (W x H x D)
• Installation Size 182 x 53 x 158mm
• Weight 1.2kg
• Unit weight in individual package 1.5kg
